• Country
• United States of America (USA)

• Manufacturer / Brand
• Stewart Warner Corp.; Chicago (IL)

• Year
• 1934

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 79154

• • Brand: Ferrodyne

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6A7 6D6 75 41 80

• Main principle
• Superheterodyne (common); ZF/IF 456 kHz

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) /   Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• from Radiomuseum.org
• Model: 1259 Ch= R-125A - Stewart Warner Corp.; Chicago

• Notes
• Model 1259 uses chassis R125; mains supply 115 V (60 cycles) or 100-240 V (25-133 cycles, phono model / export model).

• Circuit diagram reference
• Rider's Perpetual, Volume 5 = ca. 1934 and before

• Literature/Schematics (1)
• Rider's Perpetual, Volume 6

• Author
• Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
