- Country
- United States of America (USA)
- Manufacturer / Brand
- Stewart Warner Corp.; Chicago (IL)
- Year
- 1952 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 61384
-
- Brand: Ferrodyne
SAMS Photofact Set 140 Folder 12 Date 7-51
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); ZF/IF 455/10700 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm
- Power out
- 2.8 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 9150-DZ - Stewart Warner Corp.; Chicago
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 36 x 34 x 18 mm / 1.4 x 1.3 x 0.7 inch
- Notes
- For additional data, see model 91550-B
- Net weight (2.2 lb = 1 kg)
- 54.4 kg / 119 lb 13.2 oz (119.824 lb)
- External source of data
- Ernst Erb
- Source of data
- The Radio Collector's Directory and Price Guide 1921 - 1965
- Circuit diagram reference
- Rider's Perpetual, Volume 22, covering 1951
