- Country
- United States of America (USA)
- Manufacturer / Brand
- Stewart Warner Corp.; Chicago (IL)
- Year
- 1949 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 222383
-
- Brand: Ferrodyne
SAMS Photofact Folder 4912-12
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 25
- Valves / Tubes
- 6BH6 6J6 12AU6 12AU6 12AU6 12AU6 12AL5 12AU6 12AU7 12AU6 19T8 50L6 12AU6 12SN7 50L6 12SN7 50B5 50B5 50B5 35Z5 35Z5 35L6 35L6 1B3 10BP4
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC)
- Loudspeaker
- 2 Loudspeakers / Ø 6 inch = 15.2 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: AVT 1 - Stewart Warner Corp.; Chicago
- Shape
- Console, Highboy (legs > 50 %).
- Notes
- Channels 2 through 13.
- Mentioned in
- Photofact Folder, Howard W. SAMS (Volume 7 Set #64 Folder 4912-12, 06/1949)
- Author
- Model page created by Friedrich Weber † 12.09.2014. See "Data change" for further contributors.
