Spark Transmitter No. 2683
Stoelting Co.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Stoelting Co.; Chicago, IL
- Year
- 1912
- Category
- Commercial Transmitter (TX not Transceiver)
- Radiomuseum.org ID
- 278089
- Main principle
- Transmitter
- Power type and voltage
- Storage and/or dry batteries
- Loudspeaker
- - - No sound reproduction output.
- Power out
- 5 W (undistorted)
- Material
- Various materials
- from Radiomuseum.org
- Model: Spark Transmitter No. 2683 - Stoelting Co.; Chicago, IL
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 28 x 12 x 12 inch / 711 x 305 x 305 mm
- Notes
-
Stoelting made and sold coherer and crystal receivers and spark transmitters in the early wireless era (pre-1920). Most of their wireless equipment was used in school and university labs for teaching early wireless, electrical, and physics principles to students. This is a 1912 fixed-gap spark transmitter. Note the adjustable glass plate condensers.
- Author
- Model page created by Richard Groshong. See "Data change" for further contributors.
