SSB Transceiver SSB-100
Stoner; Cucamonga, CA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Stoner; Cucamonga, CA
- Year
- 1975 ??
- Category
- Commercial Transmitter & Receiver (TRX not Amateur)
- Radiomuseum.org ID
- 179004
- Number of Tubes
- 3
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superhet with RF-stage; ZF/IF 1650 kHz; 3 AF stage(s)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Powered by external power supply or a main unit. / 13,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Power out
- 2 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: SSB Transceiver SSB-100 - Stoner; Cucamonga, CA
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 424 x 137 x 263 mm / 16.7 x 5.4 x 10.4 inch
- Notes
- HF transceiver 4 canales acristal entre 2 y 15 MHz.
SSB 50-70W PEP. AM 15W. CW 50W RF Out.
- Net weight (2.2 lb = 1 kg)
- 10 kg / 22 lb 0.4 oz (22.026 lb)
- Source of data
- - - Data from my own collection
- Author
- Model page created by Alberto Sanna-Alonso. See "Data change" for further contributors.
