• Country
• United States of America (USA)

• Manufacturer / Brand
• Stromberg-Carlson Co. ; Rochester (NY)

• Year
• 1946/1947

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 187041

• • Brand: Te-Lek-Tor-Et

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 16

• Valves / Tubes
• 6SG7 6SB7Y 6SG7 6SH7 6SJ7 6SJ7 6H6 6SQ7 6SL7 6SQ7 6U5G 6SQ7 6SN7 6L6GT 6L6GT 5R4G

• Main principle
• Superheterodyne (common)

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Material
• Wooden case

• from Radiomuseum.org
• Model: 1135 PLW - Stromberg-Carlson Co. ;

• Shape
• Console, Lowboy (legs < 50 %).

• Notes
• Cabinet is in 18th Century available in either mahogany or walnut veneers.

• Mentioned in
• Radio Retailing (Radio & Television R.) (February 1947 page 36.)

• Literature/Schematics (4)
• Photofact Folder, Howard W. SAMS (Set 23, Date 9/47, Folder 4713-26)

• Author
• Model page created by Ernst Erb. See "Data change" for further contributors.
