410-T Ch= 410

Stromberg-Carlson Co. ; Rochester (NY)

Data
Forum
Pictures
Collections

  • Year
  • 1939–1941
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 62157
    • Brand: Te-Lek-Tor-Et

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Alternating Current supply (AC) / 105-125 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 410-T Ch= 410 - Stromberg-Carlson Co. ;
  • Shape
  • Console, Highboy (legs > 50 %).
  • Dimensions (WHD)
  • 610 x 740 x 270 mm / 24 x 29.1 x 10.6 inch
  • Notes

  • Info from Tom Dailey, Denver, Colerado, USA:
    It has 3 brass-tipped (footed) legs, curving down from a central carved wooden pillar, which supports the radio cabinet. The shape (of the cabinet) is roughly oval, with the front and rear edges being straight. It stands 74cm from floor to top of cabinet, 27cm front-to-back deep, 36cm thick (the radio cabinet, itself), with the cabinet being 61cm wide.

    The most interesting feature is that the front of the radio cabinet, fitted with 2 oval brass knobs, "unsnaps", and drops down on bottom-mounted hinges, lying horizontally, by means of fold-up bracing arms.

    The physical appearance of the table and free-standing radio cabinet are identical, with a brass-rimmed printed-paint-on-glass "slide-rule" dial, and 4 knobs, the last 2 being concentric (on/off volume, tone switch, band selection, and in center - tuning). For 50 to 60 Hz AC.

  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 11 = ca. 1940 and before
  • Mentioned in
  • Rider's 11-7, 11-8, 11-10, 11-17
