- Country
- United States of America (USA)
- Manufacturer / Brand
- Stromberg-Carlson Co. ; Rochester (NY)
- Year
- 1940
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 62192
-
- Brand: Te-Lek-Tor-Et
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 12
- Main principle
- Superhet with RF-stage; ZF/IF 455/2100 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s) 11 FM circuit(s)
- Wave bands
- Broadcast, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 10.2 inch = 25.9 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 455-M - Stromberg-Carlson Co. ;
- Shape
- Console with Push Buttons.
- Dimensions (WHD)
- 26.2 x 42.5 x 13.2 inch / 665 x 1080 x 335 mm
- Notes
- Standard Broadcast: 540 to 1700 MHz, ShortWave: 5.7 to 18 MHz, Frequency Modulation: 40 to 44 MHz (Obsolete) . Six station buttons for BC band, tuning eye, push-pull audio amplifier.
- External source of data
- Ernst Erb
- Source of data
- Pre-War Consoles
- Circuit diagram reference
- Rider's Perpetual, Volume 11 = ca. 1940 and before
- Mentioned in
- Rider's 11-37 to 11-40
