• Country
• United States of America (USA)

• Manufacturer / Brand
• Stromberg-Carlson Co. ; Rochester (NY)

• Year
• 1940/1941

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 170154

• • Brand: Te-Lek-Tor-Et

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• 6SK7 6SA7 6SK7 6SQ7 6U5 6V6GT 5Y3G

• Main principle
• Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: 520-L - Stromberg-Carlson Co. ;

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 26.75 x 42 x 12.125 inch / 679 x 1067 x 308 mm

• Notes

• BC (540-1600 kHz) and SW (5.7-18.0 MHz) bands. Tuning eye. For 50 to 60 Hz AC. Pushbutton tuning.

• Source of data
• Pre-War Consoles

• Circuit diagram reference
• Rider's Perpetual, Volume 12 = ca. 1941 and before

• Mentioned in
• Rider's 12-10, 12-11, 12-12

• Author
• Model page created by Götz Linss † 27.06.21. See "Data change" for further contributors.
