• Country
• Australia

• Manufacturer / Brand
• Stromberg-Carlson (Australasia) Pty. Ltd. Sydney

• Year
• 1932

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 297887

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 224 235 224 247 280

• Main principle
• Superheterodyne (common); ZF/IF 175 kHz; 1 AF stage(s); Anode bend detection

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 240 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Convertible Ch= 532 - Stromberg-Carlson Australasia

• Shape
• Console, Lowboy (legs < 50 %).

• Price in first year of sale
• 39.50 Aus£

• Mentioned in
• Wireless Weekly (Australia) (W.W. "The Superheterodyne Book", advert, P54.)

• Literature/Schematics (1)
• - - Manufacturers Literature ((Stromberg Carlson Service Data, Drawing No. 33, 4/5/1932.)

• Literature/Schematics (2)
• Radio and Electrical Merchant (Volume 6, No. 24, 13/7/1934, Page 22.)

• Literature/Schematics (3)
• Radio Trade Annual of Australia (6th Edition 1938, Page 330.)

• Literature/Schematics (4)
• Mingay's "Radio Diagram & I.F. Index

Stromberg-Carlson 532.

128 KB

• Documents regarding this model

• Author
• Model page created by Stuart Irwin. See "Data change" for further contributors.
