Dynamic Tube Tester 85

• Country
• United States of America (USA)

• Manufacturer / Brand
• Superior Instruments Co.; New York (NY)

• Year
• 1959

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 122455

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110 - 120 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Dynamic Tube Tester 85 - Superior Instruments Co.; New

• Shape
• Tablemodel, with any shape - general.

• Notes
• Five valve holders, one instrument, neon lamp, manual test voltage adjustment.

• Source of data
• -- Collector info (Sammler)

• Author
• Model page created by a member from A. See "Data change" for further contributors.

• Other Models

• Here you find 50 models, 50 with images and 16 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
