• Country
• United States of America (USA)

• Manufacturer / Brand
• Supreme Instruments Corp.; Greenwood (MS)

• Year
• 1940

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 118004

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• 6A8 37 6X5

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110-125 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Wooden case

• from Radiomuseum.org
• Model: RF Signal Generator 571 - Supreme Instruments Corp.;

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 9 x 8 x 7 inch / 229 x 203 x 178 mm

• Notes
• 5 RF ranges: A) 65-205 kHz, B) 205-650 kHz, C) 350-2050 kHz, D) 2050-6500 kHz, E) 6,5-20.5 MHz.
  400 Hz AM internal modulation.

• Net weight (2.2 lb = 1 kg)
• 0.4 kg / 0 lb 14.1 oz (0.881 lb)

• Price in first year of sale
• 38.00 $

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by Meyer Rochwerger. See "Data change" for further contributors.
