Transmitter 600-T
Swan Electronics, Oceanside, CA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Swan Electronics, Oceanside, CA
- Year
- 1971–1975
- Category
- Amateur Transmitter (only)
- Radiomuseum.org ID
- 289188
QST April 1971 page 115
QST April 1971 page 115
- Number of Tubes
- 9
- Main principle
- Transmitter
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Transmitter 600-T - Swan Electronics, Oceanside,
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 15 x 6.5 x 12 inch / 381 x 165 x 305 mm
- Notes
-
The Swan 600-T Transmitter operates on the 80, 40, 20, 15 and 10 meter amateur bands in SSB (600 PEP), CW (500 watts), AM (150 watts) and AFSK (100 watts).
The 600-T matches the Swan 600-R Receiver.
- Net weight (2.2 lb = 1 kg)
- 35 lb (35 lb 0 oz) / 15.890 kg
- Price in first year of sale
- 495.00 USD
- Mentioned in
- QST (April 1971 page 115)
- Literature/Schematics (1)
- Tube Type Transmitters (2nd edition page 262 and 263)
- Literature/Schematics (2)
- Transmitters Exciters & Power Amplifiers (page 122)
- Author
- Model page created by Wayne Childress. See "Data change" for further contributors.
