Calypso DO-12
Swing Electroimpex GmbH, Frankfurt
- Country
- Germany
- Manufacturer / Brand
- Swing Electroimpex GmbH, Frankfurt
- Year
- 1972
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 180642
- Number of Transistors
- 9
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Dry Batteries / AA: 2 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.25 cm = 2.1 inch
- Power out
- 0.25 W (unknown quality)
- Material
- Various materials
- from Radiomuseum.org
- Model: Calypso DO-12 - Swing Electroimpex GmbH,
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 72 x 142 x 32 mm / 2.8 x 5.6 x 1.3 inch
- Notes
-
Pocket type radio with LED tuning indicator for both AM and FM, round metal speaker grill, rod antenna.
Calypso was a Registered Trade Mark for Wegner (Swing Electroimpex).Made in Hong-Kong
- Net weight (2.2 lb = 1 kg)
- 0.260 kg / 0 lb 9.2 oz (0.573 lb)
- Author
- Model page created by Eckhard Wegner. See "Data change" for further contributors.
