• Country
• Germany

• Manufacturer / Brand
• Swing Electroimpex GmbH, Frankfurt

• Year
• 1970 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 177466

• Number of Transistors
• 8

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.25 cm = 2.1 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Epic Eight Transistor Radio - Swing Electroimpex GmbH,

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 66 x 108 x 34 mm / 2.6 x 4.3 x 1.3 inch

• Notes
• Epic Eight Transistor Radio,with carrying case, made in Hongkong, sold exclusive to the shops of Schickedanz KG., Germany.Weight shown is gross including packing .

• Net weight (2.2 lb = 1 kg)
• 0.250 kg / 0 lb 8.8 oz (0.551 lb)

• Author
• Model page created by Eckhard Wegner. See "Data change" for further contributors.

• Other Models

• Here you find 155 models, 137 with images and 44 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Swing Electroimpex GmbH, Frankfurt
