Gramo Old Horn Type Gramophone CP-101 (senn-sound)
Swing Electroimpex GmbH, Frankfurt
- Country
- Germany
- Manufacturer / Brand
- Swing Electroimpex GmbH, Frankfurt
- Year
- 1964–1968
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 248530
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 4
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Record Player (not changer)
- Power type and voltage
- Dry Batteries / UM2: 4 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Power out
- 0.3 W (unknown quality)
- Material
- Various materials
- from Radiomuseum.org
- Model: Gramo Old Horn Type Gramophone CP-101 - Swing Electroimpex GmbH,
- Shape
- Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
- Dimensions (WHD)
- 185 x 0 x 215 mm / 7.3 x 0 x 8.5 inch
- Notes
-
Gramo CP-101 , Höhe incl Horn 315 mm , Bruttogewicht incl Originalverpackung 1,4 kg. Made in Japan.
33/45 U/min
- Net weight (2.2 lb = 1 kg)
- 0.920 kg / 2 lb 0.4 oz (2.026 lb)
- Author
- Model page created by Eckhard Wegner. See "Data change" for further contributors.
