• Country
• United States of America (USA)

• Manufacturer / Brand
• Sylvania (Hygrade, GTE, Nilco); Emporium (PA)

• Year
• 1959 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 149143

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 16

• Valves / Tubes
• 2CY5 5U8 3BZ6 3BZ6 3BZ6 8ET7 5BR8 6BN8 5AQ5 3CS6 10EG7 6CG7 12DQ6A 12AX4GTA 1G3GT 17BWP4

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 110 - 120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• from Radiomuseum.org
• Model: 17P11 Series Ch= 547-2 - Sylvania Hygrade, GTE, Nilco;

• Notes
• CAUTION: One side of AC line connected to chassis. Channels 2 thru 13 VHF: Sams photofact set 500 folder 2 date9-60 features the Sylvania models 17B110, 17M101 and 17P11 Series with chassis 547-1 or 547-2 as the same schematic.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 500 folder 2 date 9-60)

• Author
• Model page created by Peter Hoddow. See "Data change" for further contributors.
