• Country
• United States of America (USA)

• Manufacturer / Brand
• Sylvania (Hygrade, GTE, Nilco); Emporium (PA)

• Year
• 1958

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 179084

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• 2N212 2N94 2N94 2N35 2N214 2N214

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / C: 6 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: T6 Super-6-Transistor 3305TA - Sylvania Hygrade, GTE, Nilco;

• Shape
• Portable set > 8 inch (also usable without mains)

• Notes
• The Sylvania Model 3205TA is a battery operated portable AM transistorized Receiver.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Date 8-58, Set 410, Folder 17)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
