4901 Ch= 1-628-1
Sylvania (Hygrade, GTE, Nilco); Emporium (PA)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sylvania (Hygrade, GTE, Nilco); Emporium (PA)
- Year
- 1958 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 181405
Sams Photofact Folders reference picture.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 110 - 120 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 6 inch = 15.2 cm
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: 4901 Ch= 1-628-1 - Sylvania Hygrade, GTE, Nilco;
- Shape
- Tablemodel, with any shape - general.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 6-58, Set 404, Folder 10)
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
