4P19WC Ch= 682-3
Sylvania (Hygrade, GTE, Nilco); Emporium (PA)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sylvania (Hygrade, GTE, Nilco); Emporium (PA)
- Year
- 1961
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 88649
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 4
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Tuned circuits
- 4 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.75 inch = 7 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 4P19WC Ch= 682-3 - Sylvania Hygrade, GTE, Nilco;
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Notes
-
Battery Operated Transistorized AM Receiver.
The circuit is about the same in all the five following models: 4P19W, 4P19WC, 4P19WD, TH10W and 7058
- Circuit diagram reference
- Beitman Radio Diagrams Vol. 22, 1962
- Mentioned in
- Antique Radio Magazine - Italy, Club Antique Radio Magazine ((n. 129 gennaio-febbraio 2016, pag. 36-39))
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 4-62, Set 573, Folder 16)
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
