• Country
• United States of America (USA)

• Manufacturer / Brand
• Sylvania (Hygrade, GTE, Nilco); Emporium (PA)

• Year
• 1952 ?

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 355488

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• 6BA6 6BE6 6BA6 6AV6 6AV6 6V6GT 6V6GT 6X5GT

• Main principle
• Superhet with RF-stage; ZF/IF 265 kHz

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: Ford Mercury 2CM752 - Sylvania Hygrade, GTE, Nilco;

• Shape
• Chassis only or for «building in»

• Notes

• Mercury model 2CM752 is a battery operated custom built automobile superheterodyne receiver.
  Vibrator G1 for +B.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 167, folder 7, dated 5-52)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
