100A Pulse Generator

• Country
• United States of America (USA)

• Manufacturer / Brand
• Systron Donner; Concord CA

• Year
• 1968 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 328063

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 35

• Semiconductors
• 2N2369A 2N6305 2N6305 2N6305 2N6305 2N3640 2N6305 2N6305 2N6305 2N3640 2N5087 2N3565 2N2369A 2N3565 2N5087 2N3640 2N3640 2N2369A 2N6305 2N3640 FT1702 2N6305 2N2369A 2N2369A 2N2894 2N2894 2N4918 2N4921 40250 2N1535 2N3605 2N3640 2N3605 2N3640 2N3605

• Power type and voltage
• Alternating Current supply (AC) / 105-125 or 210-230 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: 100A Pulse Generator - Systron Donner; Concord CA

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 8.5 x 3.5 x 11 inch / 216 x 89 x 279 mm

• Notes

• The rectangular amplitude, width, delay and repetition are continuously adjustable. The frequency range is 0.1 Hz-10MHz. The outputs are designed for a 50 ohm resistance load. For the transistor type 2N6305, the types 2N3646, MPS3646 or ME9021 have also been installed.

  Die Rechteck-Amplitude, -Weite,- Verzögerung und -Wiederholung sind stufenlos einstellbar. Der Frequenzbereich beträgt 0,1 Hz-10MHz. Die Ausgänge sind ausgelegt für 50 Ohm Widerstandslast. Für den Transistortyp 2N6305 sind auch die Typen 2N3646, MPS3646 oder ME9021 verbaut worden.

• Net weight (2.2 lb = 1 kg)
• 3.3 kg / 7 lb 4.3 oz (7.269 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Günter Kudicke. See "Data change" for further contributors.
