CD-Player Pulsar CD 1200 R

T+A Elektroakustik; Herford

Data
Forum
Pictures
Collections

  • Year
  • 1994 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 229981

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC) / 230 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: CD-Player Pulsar CD 1200 R - T+A Elektroakustik; Herford
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 440 x 75 x 390 mm / 17.3 x 3 x 15.4 inch
  • Notes

  • Technische Daten:

    • Klirrfaktor / Intermodulation < 0,002 %.
    • eff. Systemdynamik 97 dB
    • Geräusch-/ Fremdspannungsabstand 109 dB/ 106 dB
    • Kanaltrennung 1 kHz / 10 kHz 106 / 100 dB
    • Frequenzgang 2 Hz – 20 kHz
    • Analog-Ausgang Cinch: nominal 2,6 V eff
    • Ausgangsimpedanz: 22 Ohm
    • Digitalausgang Datenformat SP-DIF, TOS Link
    • 1 x Opto = 660 nm / -18 dBm, optional: 1 x Coax = 0,5 V / 75 Ohm
    • RC-IN, RC-Out
    • Anschlüsse für Fernbedienung (optional) über R-System, Infrarot-Empfänger E2000 und Geber F2000AC
    • CD-Laufwerk: CDM-9 (Philips)
    • Netzanschluss: 230 V, 50 Hz 16 VA
  • Net weight (2.2 lb = 1 kg)
  • 8 kg / 17 lb 9.9 oz (17.621 lb)
  • Price in first year of sale
  • 2,500.00 DM
  • Source of data
  • -- Original prospect or advert
  • Author
  • Model page created by Eberhard Fuchs. See "Data change" for further contributors.
