Radio - Intercom 1014
Talk-A-Radio; Dallas, Texas
- Country
- United States of America (USA)
- Manufacturer / Brand
- Talk-A-Radio; Dallas, Texas
- Year
- 1958 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 253962
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Radio with other functions
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Metal case
- from Radiomuseum.org
- Model: Radio - Intercom 1014 - Talk-A-Radio; Dallas, Texas
- Shape
- Miscellaneous shapes - described under notes.
- Dimensions (WHD)
- 16.18 x 11.75 x 5 inch / 411 x 298 x 127 mm
- Notes
-
Recessing wall mounted AM/FM clock radio with intercom system. Phono input. Internal 4" x 6" speaker.
- Author
- Model page created by Mark Skala. See "Data change" for further contributors.
