5-3 60 Hz
Tandberg Radio; Oslo
- Country
- Norway
- Manufacturer / Brand
- Tandberg Radio; Oslo
- Year
- 1960
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 132833
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 110-245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: 5-3 [60 Hz] - Tandberg Radio; Oslo
- Shape
- Tablemodel, with any shape - general.
- Notes
- Tandberg 5-3, Tape Recorder.
60 Hz version.
Imported to US by Tandberg of America, Inc., 8 Third Ave., Pelham, NY. Oval speaker 4" × 7". Sams photofact set 480 folder 14 date 4-60 features the Tandberg models 5, 5-1, 5-2, 5-2-266, 5-3 and 241 as the same schematic.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (4-1960 Set 480 Folder 14)
