• Country
• Norway

• Manufacturer / Brand
• Tandberg Radio; Oslo

• Year
• 1967–1970

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 71333

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• ECC85 ECH81 EF89 EM84

• Number of Transistors
• 16

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Sølvsuper - Soelvsuper 10 SS10-70 - Tandberg Radio; Oslo

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 540 x 130 x 230 mm / 21.3 x 5.1 x 9.1 inch

• Notes

• There are three versions of Sølvsuper 10:

  • Soelvsuper 10-70: mono, with built-in speaker
  • Soelvsuper 10-71: stereo, for use with external speakers
  • Soelvsuper 10-72: stereo, with two built-in speakers

  In the last production season 1969/1970, two additional push-buttons (AFC and power) were added.

  Available in three cabinet materials: teak (789,- NOK), palisander (850,- NOK) and oak (995,- NOK).

  There is also a TV radio combination Sølvsuper TV-473 that uses a Sølvsuper 10 chassis.

• Price in first year of sale
• 995.00 NOK

• Literature/Schematics (1)
• -- Original prospect or advert

• Author
• Model page created by Ernst Rykkje. See "Data change" for further contributors.
