TCM Weltempfänger 216393

TCM (Tchibo "Marke" / "brand"), Hamburg

Data
Forum
Pictures
Collections

  • Year
  • 1999 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 337128

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
  • Power type and voltage
  • Batteries / addl. power jack / AA: 2 x 1.5 / 3 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: TCM Weltempfänger 216393 - TCM Tchibo "Marke" / "brand",
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 150 x 90 x 35 mm / 5.9 x 3.5 x 1.4 inch
  • Notes

  • Kurzwellenbereiche in MHz:

    1:  5,80 - 6,20
    2: 7,10 - 7,60
    3: 9,40 - 9,90
    4: 11,40 - 12,10
    5: 15,00 - 15,65
    6: 17,35 - 18,15

  • Net weight (2.2 lb = 1 kg)
  • 0.350 kg / 0 lb 12.3 oz (0.771 lb)
  • Author
  • Model page created by Siegfried Raedel. See "Data change" for further contributors.
