• Country
• Japan

• Manufacturer / Brand
• TEAC; Tokyo

• Year
• 2001 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 322075

• • Brand: Tascam

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• PLL, Phase-locked loop

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 230 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 35 W (max.)

• Material
• Metal case

• from Radiomuseum.org
• Model: AM/FM Stereo Receiver AG-H300 - TEAC; Tokyo

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 215 x 110 x 300 mm / 8.5 x 4.3 x 11.8 inch

• Notes

• - AM/FM Tuner + Amplifier
  - Antenna inputs separated for AM loop and FM 75Ω
  - Inputs: Phono, AUX, CD, CD-R, Tape
  - Outputs: for two speakers 8-16Ω, headphones

  Made in China

• Net weight (2.2 lb = 1 kg)
• 4 kg / 8 lb 13 oz (8.811 lb)

• Author
• Model page created by Julián Muñoz Lorenzo. See "Data change" for further contributors.
