• Country
• Japan

• Manufacturer / Brand
• TEAC; Tokyo

• Year
• 1986–1988

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 153257

• • Brand: Tascam

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Alternating Current supply (AC) / 120; 220; 240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Cassette Deck V-770 - TEAC; Tokyo

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 435 x 120 x 265 mm / 17.1 x 4.7 x 10.4 inch

• Notes

• Frontloading 3-Head Stereo Cassette Deck with Dolby B + C, Double Dolby NR Circuits, Dolby HX Pro and Metal Tape Capability.
  4-Digit Digital Counter, Linear Tape Counter, Digital Peak-Reading Meters.
  2-Motor IC Logic Transport Control.

  Power requirements:
  120; 220; 240 V AC, 50/60 Hz (General export model)
  120 V AC, 60 Hz (USA / Canada)
  220 V AC, 50 Hz (Europa)
  240 V AC, 50 Hz (UK / Australia)

  Power consumption: 17 W

  Type: 3-head, single compact cassette deck
  Track System: 4-track, 2-channel stereo
  Tape Speed: 4.76 cm/s
  Heads: 1 x combination record/playback, 1 x erase
  Motor: 1 x reel, 1 x capstan, 1 x mechanism
  Tape Type: type I, CrO2, Metal
  Noise Reduction: B, C, HX Pro
  Frequency Response: 20Hz to 21kHz  (Metal tape)
  Signal to Noise Ratio: 80dB  (dolby C)
  Wow and Flutter: 0.03%
  Total Harmonic Distortion: 3%
  Input: 87mV (line)
  Output: 0.43V (line)

• Net weight (2.2 lb = 1 kg)
• 4.9 kg / 10 lb 12.7 oz (10.793 lb)

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
