• Country
• Germany

• Manufacturer / Brand
• Team Electronic GmbH; Frankfurt/Main

• Year
• 1995 ??

• Category
• Citizen Band Equipment

• Radiomuseum.org ID
• 196674

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Transceiver; ZF/IF 10695 / 455 kHz

• Wave bands
• Short Wave (SW only)

• Power type and voltage
• Alternating Current supply (AC) / 220-240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Metal case

• from Radiomuseum.org
• Model: Euro B-3104-AF - Team Electronic GmbH;

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 240 x 90 x 210 mm / 9.4 x 3.5 x 8.3 inch

• Notes
• CB Feststation, 40K FM 4W, 12K AM 1W, Regler für RF Gain; Tx Power, analoges S-Meter.

• Net weight (2.2 lb = 1 kg)
• 3.3 kg / 7 lb 4.3 oz (7.269 lb)

• Price in first year of sale
• 538.00 DM

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by a member from D. See "Data change" for further contributors.
