• Country
• Germany

• Manufacturer / Brand
• TEC Dieter Beer; Wiesbaden

• Year
• 1993 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 308481

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, more than 2 x SW plus FM or UHF.

• Power type and voltage
• Storage and/or dry batteries / 2 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 cm = 1.6 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: powerTEC 10 Band Receiver KK-9610B - TEC Dieter Beer; Wiesbaden

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 110 x 65 x 25 mm / 4.3 x 2.6 x 1 inch

• Notes

• Kann außerdem analogen Fernsehton in Band 1 (Kanäle 1 - 4) und Band 3 (Kanäle 5 - 12) empfangen. Eine integrierte Schaltung vorhanden.

• Net weight (2.2 lb = 1 kg)
• 0.150 kg / 0 lb 5.3 oz (0.33 lb)

• Author
• Model page created by Ingolf Pabst. See "Data change" for further contributors.
