Sound Admiral 4
TEC Dieter Beer; Wiesbaden
- Country
- Germany
- Manufacturer / Brand
- TEC Dieter Beer; Wiesbaden
- Year
- 1982
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 141365
(D) TEC Katalog 6200 Wiesbaden ~1982
- Number of Transistors
- 2
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Dry Batteries / 6R61: 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
- Power out
- 0.1 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Sound Admiral 4 - TEC Dieter Beer; Wiesbaden
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 80 x 135 x 35 mm / 3.1 x 5.3 x 1.4 inch
- Notes
-
AM/FM Taschenradio mit Ohrhörerbuchse.
FM-Empfang über 40 cm Teleskopantenne; AM-Empfang über eingebaute Ferritantenne.
Gehäusefarbe Silber.FTZ-Nr. U 188
Art.-Nr. 1/33
- Net weight (2.2 lb = 1 kg)
- 0.3 kg / 0 lb 10.6 oz (0.661 lb)
- Source of data
- -- Original prospect or advert
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
