• Country
• Japan

• Manufacturer / Brand
• Technics (brand)

• Year
• 1995

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 285122

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• CD-Player, -Writer, MD, MOD (audio); Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 230-240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Compact Disc Player SL-PG370A - Technics brand

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 430 x 92 x 283 mm / 16.9 x 3.6 x 11.1 inch

• Notes

• Technics Frontloading Single Compact Disc Player Model SL-PG370A.
  Disc format: CD - RAE1100Z Mechaism Series
  Digital converter: 1 bit MASH
  Frequency response: 2Hz to 20kHz
  Dynamic range: 92dB
  Signal to Noise Ratio: 100dB
  Total harmonic distortion: 0.007%
  Line output: 2V
  Power Consumption 13 Watts.
  Finish: Black metallic


  Suffix for Areas:
  E - Europe
  EB - Britain
  EG - German and Italy
  ER - Hungary
  EZ - Poland and Russia

• Net weight (2.2 lb = 1 kg)
• 3.1 kg / 6 lb 13.3 oz (6.828 lb)

• Mentioned in
• - - Manufacturers Literature (Service Manual)

• Literature/Schematics (1)
• -- Original prospect or advert (Technics Catalogue - 'HiFi')

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
