LW/MW/FM Stereo Receiver SA-GX200L EB (United Kingdom Model)

Technics (brand)

Data
Forum
Pictures
Collections

  • Year
  • 1990
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 274686

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC) / 50/60 Hz, 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 80 W (undistorted)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: LW/MW/FM Stereo Receiver SA-GX200L [EB ] - Technics brand
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 430 x 124 x 300 mm / 16.9 x 4.9 x 11.8 inch
  • Notes

  • Technics LW/MW/FM Stereo Receiver Model SA-GX200L(EB-United Kingdom).
    Continuous Power output: 40 watts per channel into 8Ω (stereo)
    Frequency response: 7Hz to 40kHz
    Total harmonic distortion: 0.05%
    Bass- & Treble Control
    Loudness
    Inputs:
    Phono, CD, VCR1, VCR2, Tape
    Input sensitivity: 3mV (MM), 200mV (line)
    Signal to noise ratio: 80dB (MM), 90dB (line)
    Output: 200mV (line)
    Speaker load impedance: 4Ω (minimum)
    Tuning Range:
    FM 87,5 - 108 MHz
    MW 522 - 1611 kHz (9kHz Steps), 530 - 1620 kHz (10kHz Steps)
    LW 155 - 353 kHz (9kHz Steps), 153 - 351 kHz (-2kHz Shift)
    24 channel random preset tuning
    Power Consumption max. 360 Watts

  • Net weight (2.2 lb = 1 kg)
  • 6.5 kg / 14 lb 5.1 oz (14.317 lb)
  • Mentioned in
  • - - Manufacturers Literature (Service Manual)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
