• Country
• Japan

• Manufacturer / Brand
• Technics (brand)

• Year
• 1983

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 124065

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Quartz Direct Drive SL-Q200 [KEG] - Technics brand

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 430 x 99 x 380 mm / 16.9 x 3.9 x 15 inch

• Notes
• Quartzgesteuerter Direktantrieb, 33 & 45 upm, Halbautomat, EPC-P30 System, Lift, STOP Taste
  Gehäusefarben Schwarz oder Silber.

• Net weight (2.2 lb = 1 kg)
• 4.6 kg / 10 lb 2.1 oz (10.132 lb)

• Source of data
• - - Data from my own collection

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by Guido Höh. See "Data change" for further contributors.
