• Country
• Japan

• Manufacturer / Brand
• Technics (brand)

• Year
• 1982

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 155201

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Cassette Deck RS-M206 - Technics brand

• Shape
• Book-shelf unit.

• Notes
• Frontloading 2-Head Stereo Cassette Deck with Dolby B and Metal Tape Capability.
  Analog Needle Meters, 3-Digit Mechanical Counter.

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
