• Country
• Japan

• Manufacturer / Brand
• Technics (brand)

• Year
• 1986/1987

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 154767

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 4

• Semiconductors
• 2SC2274 2SA984 2SC2274 2SC2274 AN6555 M5229 M5229

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Graphic Equalizer SH-8028 - Technics brand

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 430 x 86 x 194 mm / 16.9 x 3.4 x 7.6 inch

• Notes
• Technics Stereo Graphic Equalizer SH-8020.
  Band level controls: +12 dB ~ -12 dB, 7 elements per channel
  Channel separation 1 kHz: 70 dB
  Center frequency: 63 Hz, 160 Hz, 400 Hz, 1 kHz, 2.5 kHz, 6.3 kHz, 16 kHz
  Controls: equalizer on/off, input selector tape/source, rec mode EQ/straight
  Connectors: Line In L/R, Line Out L/R, Tape Rec Out L/R, Playback L/R. Power consumption: 7 W.

  Available in silver or black body. Different mains per country.
  USA/Canada: 120 V, 60 Hz
  UK/Australia: 240 V, 50/60 Hz
  Continental Europe: 220 V, 50/60 Hz
  Other areas: 110 - 127 V, 220 - 240 V, 50/60 Hz.

• Net weight (2.2 lb = 1 kg)
• 2.1 kg / 4 lb 10 oz (4.626 lb)

• Price in first year of sale
• 160.00 $

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
