Sony Solid State Digimatic TFM-C540H

Tedelex, Johannesburg

Data
Forum
Pictures
Collections

  • Year
  • 1975 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 338412

 Technical Specifications

  • Number of Transistors
  • 10
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 50Hz, 230 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Sony Solid State Digimatic TFM-C540H - Tedelex, Johannesburg
  • Shape
  • Tablemodel with Clock ((Alarm-) Clock Radio).
  • Dimensions (WHD)
  • 170 x 115 x 167 mm / 6.7 x 4.5 x 6.6 inch
  • Notes

  • AM/FM digital clock radio.

    AM: 530~1605 kHz
    FM: 87.5~108 MHz

    Manufactured by Television & Electrical Distributors (Pty.) Ltd. in Johannesburg (South Africa) under the licence of Sony Corp. Tokyo, Japan.

    See also the 60Hz 120 volt version Sony Digimatic TFM-C540W

  • Net weight (2.2 lb = 1 kg)
  • 1 kg / 2 lb 3.2 oz (2.203 lb)
  • Author
  • Model page created by Martin Kent. See "Data change" for further contributors.
