• Country
• Germany

• Manufacturer / Brand
• Tefi-Apparatebau; Porz bei Köln

• Year
• 1960–1962

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 17271

Click on the schematic thumbnail to request the schematic as a free document.

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (MW) and Long Wave.

• Details
• Other Combination - see Notes

• Power type and voltage
• Line / Batteries (any type)

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet.

• from Radiomuseum.org
• Model: Holiday Super II BK60AM - Tefi-Apparatebau; Porz bei

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 300 x 225 x 118 mm / 11.8 x 8.9 x 4.6 inch

• Notes
• Eingebauter Schallbandspieler. Vier Tasten, kuzer Trageriemen.

• Net weight (2.2 lb = 1 kg)
• 4.6 kg / 10 lb 2.1 oz (10.132 lb)

• External source of data
• E. Erb 3-907007-36-0

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Mentioned in
• Historische Radios Band II (161)

• Literature/Schematics (1)
• H. Jüttemann, Das Tefifon
