- Country
- Germany
- Manufacturer / Brand
- TeKaDe (TKD), Süddeutsche Telefon-Apparate- Kabel- und Drahtwerke; Nürnberg
- Year
- 1953–1955
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 19985
-
- alternative name: Felten & Guilleaume || Südd.Telefon-App., Kabel- und Drahtwerke AG || Telade
- Brand: KD
- Number of Tubes
- 17
- Valves / Tubes
- PCC84 ECC81 EF80 EF80 EF80 EB41 PL83 EF80 PABC80 PL82 ECL80 ECL80 ECL80 PL81 PY81 EY51 Bm35R-2 or MW36-44
- Number of Transistors
- Semiconductors
- Diode_Ge Selengleichrichter
- Main principle
- Superhet with RF-stage; ZF/IF 27250 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- AC/DC-set / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Wooden case
- from Radiomuseum.org
- Model: FS1040 - TeKaDe TKD, Süddeutsche
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 620 x 450 x 440 mm / 24.4 x 17.7 x 17.3 inch
- Notes
-
10 Kanäle im VHF-Bereich Band I und III. Lautsprecher frontseitig 9 x 15,5 cm.
Preis im Folgejahrgang 1954/55 748,- DM
- Net weight (2.2 lb = 1 kg)
- 27.5 kg / 60 lb 9.2 oz (60.573 lb)
- Price in first year of sale
- 998.00 DM
- External source of data
- Erb
- Source of data
- Kat.d.Rundf.GrossH.1953/54
- Mentioned in
- Rundfunk- und Fernseh-Katalog 1953/54 (S.143)
- Literature/Schematics (1)
- Rundfunk-Phono-Fernseh-Katalog 1953-1954 S.105 (Thiele)
- Literature/Schematics (2)
- Rundfunk-Phono-Fernseh-Katalog 1954-1955 S.98 (Thiele)
- Literature/Schematics (3)
- Rundfunk-Phono-Fernseh-Katalog 1954-1955 2. Aufl. S.132 (Thiele)
