• United States of America (USA)

• Manufacturer / Brand
• Tektronix; Portland, OR

• Year
• 1963–1971

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 116153

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110-248 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Oscilloscope 502A - Tektronix; Portland, OR

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 11.5 x 15.75 x 22.75 inch / 292 x 400 x 578 mm

• Notes
• Dual beam oscilloscope, DC to 1 MHz. Sensitivity up to 0.1 mV/cm with reduced 100 kHz bandwidth. 5021 dual gun CRT with P2 standard phosphor; 3 kV accelerating voltage. 502 may also be operated as dual beam X-Y display.

• Price in first year of sale
• 1,050.00 $

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by Emilio Ciardiello. See "Data change" for further contributors.
