• Country
• United States of America (USA)

• Manufacturer / Brand
• Tektronix; Portland, OR

• Year
• 1960 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 299684

• Number of Tubes
• 16

• Valves / Tubes

• Number of Transistors
• 2

• Semiconductors

• Power type and voltage
• Alternating Current supply (AC) / 50 - 60 Hz; 105 - 125 or 210 - 250 Volt

• Material
• Metal case

• from Radiomuseum.org
• Model: Type 504 Oscilloscope - Tektronix; Portland, OR

• Shape
• Boatanchor (heavy military or commercial set >20 kg).

• Dimensions (WHD)
• 9.75 x 13.5 x 21.5 inch / 248 x 343 x 546 mm

• Notes

• See Tektronix RM504 for the rack-mounted version of this oscilloscope.

• Net weight (2.2 lb = 1 kg)
• 29 lb (29 lb 0 oz) / 13.166 kg

• Author
• Model page created by Benjamin Krippner. See "Data change" for further contributors.
