- Country
- United States of America (USA)
- Manufacturer / Brand
- Tele-Tone Radio Corp., Tele-Tone Co. Inc.; New York (NY)
- Year
- 1949 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 132116
-
- alternative name: Teletone
Photofact Folders, Sams
SAMS Photofact 6/48 495-21 Set 57 Folder 21
Click on the schematic thumbnail to request the schematic as a free document.
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet.
- Material
- Wooden case
- from Radiomuseum.org
- Model: TV-249 - Tele-Tone Radio Corp., Tele-
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Notes
- Tele-Tone TV-249; 10" b/w TV with US standard VHF tuner. Mahogany cabinet.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Folder 21 Set 57 1949)
- Literature/Schematics (2)
- Photofact Folder, Howard W. SAMS (Set 136, folder 1 Production changes bulletin 21, dated 6-51)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
