• Country
• United States of America (USA)

• Manufacturer / Brand
• Tele-Tone Radio Corp., Tele-Tone Co. Inc.; New York (NY)

• Year
• 1948

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 63226

• • alternative name: Teletone

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 1R5 1U4 1S5 3S4 117Z3

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Line / Batteries (any type) / AC/DC 105-120 / 67.5 & 7.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10.5 cm = 4.1 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 152 Ch= W - Tele-Tone Radio Corp., Tele-

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 250 x 170 x 105 mm / 9.8 x 6.7 x 4.1 inch

• Net weight (2.2 lb = 1 kg)
• 1.990 kg / 4 lb 6.1 oz (4.383 lb)

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 17 = 1948 and before
