- Country
- Italy
- Manufacturer / Brand
- Telefunken Italia, Milano
- Year
- 1937/1938
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 30762
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common); ZF/IF 469 kHz
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110-220 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 30 cm = 11.8 inch
- Power out
- 10 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 791 - Telefunken Italia, Milano
- Shape
- Console: Chairside Radio.
- Dimensions (WHD)
- 570 x 920 x 450 mm / 22.4 x 36.2 x 17.7 inch
- Notes
- Indicatore ottico di sintonia.
Meter.
- Net weight (2.2 lb = 1 kg)
- 50 kg / 110 lb 2.1 oz (110.132 lb)
- Source of data
- Guida Pratica Antique Radio III (2000)
- Literature/Schematics (1)
- Il Radio Libro (E.D. Ravalico) Edizioni Hoepli
- Author
- Model page created by Alessandro De Poi. See "Data change" for further contributors.
