Andante FA-2456 FM
Telefunken Radiotécnica Ibérica; Getafe
- Country
- Spain
- Manufacturer / Brand
- Telefunken Radiotécnica Ibérica; Getafe
- Year
- 1964/1965
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 108258
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Number of Transistors
- Semiconductors
- Selenium-Rectifier
- Main principle
- Superheterodyne (common); ZF/IF 468/10700 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s) 10 FM circuit(s)
- Wave bands
- Broadcast, 2 Short Wave plus FM or UHF.
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 125; 150; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 8 inch = 20.3 cm
- Power out
- 5.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Andante FA-2456 FM - Telefunken Radiotécnica
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 293 x 269 x 630 mm / 11.5 x 10.6 x 24.8 inch
- Notes
- Usa rectificador de selenio.
OM: 540 - 1700 kHz
Banda pesquera: 1450 - 4350 kHz (206,8 - 68,9 m.)
OC1: 5,4 - 18,2 MHz (55,5 - 16,5 m.)
FM: 87,5 - 100 MHz.
- Net weight (2.2 lb = 1 kg)
- 9.7 kg / 21 lb 5.9 oz (21.366 lb)
- Price in first year of sale
- 7,800.00 ESP
- Source of data
- -- Collector info (Sammler)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Jose Antonio Gonzalez-Ruiz. See "Data change" for further contributors.
