Bajazzo compact 102C

• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1973

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 72387

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 21

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 220 / 6 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 4 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Bajazzo compact 102C - Telefunken Deutschland TFK,

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 354 x 216 x 90 mm / 13.9 x 8.5 x 3.5 inch

• Notes
• Luxemburg-Taste, Eingang für Plattenspieler, Tonband oder ext. Mikrofon (eingebautes Electret Mikrofon), Pegelanzeige über Zeigerinstrument, getrennte Höhen/Tiefen- Regler, Ausgang für ext. Lautsprecher (= Kopfhöreranschluß), 8 tlg. Teleskopantenne (90 cm), 13 Dioden, E-Nr. 301 459 214, Made in Japan

• Net weight (2.2 lb = 1 kg)
• 4.3 kg / 9 lb 7.5 oz (9.471 lb)

• Author
• Model page created by Kurt Aebischer. See "Data change" for further contributors.
