Bajazzo Compact 3000

• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1977/1978

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 112701

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 11

• Semiconductors

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 5 AM circuit(s)     11 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 110; 220 / 6 × 1,5 Volt

• Loudspeaker
• 2 Loudspeakers

• Power out
• 1.5 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Bajazzo Compact 3000 - Telefunken Deutschland TFK,

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 360 x 212 x 85 mm / 14.2 x 8.3 x 3.3 inch

• Notes

• ICs: 3.
  Ausgangsleistung bei Netzbetrieb: 7 W.

  Skalenseil : 99,5 cm lang.

• Net weight (2.2 lb = 1 kg)
• 3.325 kg / 7 lb 5.2 oz (7.324 lb)

• Source of data
• Handbuch VDRG 1977/1978

• Author
• Model page created by Harry Gehrmann. See "Data change" for further contributors.
