Cruz del Sur FE-129 /24 (TV-129 /24) Ch= N-35-116L 1970

• Country
• Spain

• Manufacturer / Brand
• Telefunken Radiotécnica Ibérica; Getafe

• Year
• 1970

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 195084

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• EF183 PCL200 PL95 PCL85 ECH84 PC92 PL504 PY88 DY87 A61-120W

• Number of Transistors
• 13

• Semiconductors
• AF239 AF139 AF106 AF121 BC207 AC122 BC147 2N4291 AF121 BF197 AF121 BF197 2N4286 AA119 BA100 BA173 OA90 OA91 OA95 E30C5 E125C500 E250C500 E62,5C5

• Main principle
• Superheterodyne (common); ZF/IF 38900 kHz; 2 AF stage(s)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 125; 220 Volt

• Loudspeaker
• 3 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Cruz del Sur FE-129 /24 Ch= N-35-116L [1970] - Telefunken Radiotécnica

• Shape
• Tablemodel, low profile (big size).

• Notes

• TV B/N con sintonizador transistorizado de VHF/UHF y TRC de 24".

  Tres altavoces: Elíptico 6" x 10"; elíptico 3" x 5" y circular de 4".

• Literature/Schematics (1)
• -- Original-techn. papers. (Anuncio La Vanguardia Española enero 1970)

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
