- Country
- Germany
- Manufacturer / Brand
- Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
- Year
- 1958 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 100928
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superhet with RF-stage; ZF/IF 460 kHz; Export model
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 100; 118; 150; 200; 230 Volt
- Loudspeaker
- 3 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: D778 WK trop. - Telefunken Deutschland TFK,
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 590 x 360 x 260 mm / 23.2 x 14.2 x 10.2 inch
- Notes
-
MW and four SW band; three speakers: one oval in front and two round lateral. Hi-Fi output stage.
Wellenbereiche
K1 11,3 m - 17,15 m
K2 16,8 m - 27,8 m
K3 27,1 m - 66,7 m
K4 62,5 m - 187,5 m
M 510 khz - 1620 khz
- Literature/Schematics (4)
- -- Original-techn. papers.
- Author
- Model page created by Bruno Gandolfo-Canepa. See "Data change" for further contributors.
- Other Models
-
Here you find 3561 models, 3146 with images and 2113 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
